ISOKING Mineral Wool Acoustic Panels are high-performance sound-absorbing materials designed for wall and ceiling applications. Made from dense mineral wool, they provide excellent noise reduction, fire resistance, and moisture protection.
The panels can be installed with metal keels and hanging systems for efficient and secure mounting. Custom sizes, thicknesses, and finishes are available to meet the diverse requirements of offices, studios, and commercial interiors.
ISOKING®Mineral Wool Acoustic Panels – Fire-Resistant, Customizable, and Complete Installation Solution
Key Features
| Feature | Description |
|---|---|
| Fire Resistance | Panels meet A1 fire rating standards, ensuring safety in commercial and public spaces. |
| Customizable Design | Sizes, thicknesses, and finishes can be tailored to project specifications, providing flexibility for both acoustic performance and aesthetic requirements. |
| Complete Installation Options | Compatible with metal keel frames and hanging rods, this solution provides a one-stop option for wall and ceiling mounting. |
| Sound Absorption | NRC values range from 0.8to 0.9, depending on thickness, providing effective reduction of echo, reverberation, and overall ambient noise. |
| Moisture and Environmental Resistance | Panels are formaldehyde-free, low VOC, and resistant to mold and moisture, ensuring long-term durability. |
| Stock Availability | Large inventory ensures rapid fulfillment for both small and large-scale projects. |
Panel Types and Specifications
| Panel Type | Standard Sizes (mm) | Thickness (mm) | Surface Finish | Installation Method |
|---|---|---|---|---|
| Standard Mineral Wool Panel | 600×600, 600×1200 | 25–50 | Customizable | Wall or ceiling mounting with optional keel and hanging rod |
| High-Density Mineral Wool Panel | 1200×1200 | 50–100 | Customizable | Modular wall or ceiling installation |
| Custom Panels | Any dimensions | Any thickness | Customizable | One-stop installation solution with keel and hanging rod |
APPLICATION FIELDS OF ISOKING MINERAL WOOL CEILING PANELS
1. Office and Corporate Spaces
Modern office buildings often face noise reflection and poor speech clarity. ISOKING mineral wool ceiling panels can reduce reverberation time by up to 45 percent, improving sound comfort and privacy.
The panels reach an NRC value between 0.80 and 0.90, effectively absorbing mid and high frequencies. Their white finish increases indoor light reflection by about 15 percent, helping reduce lighting energy costs.
Common applications include conference rooms, open offices, and call centers.
2. Educational Facilities
Classrooms, lecture halls, and libraries require clear sound transmission and safety. ISOKING mineral wool panels improve speech clarity by up to 20 percent while meeting EN13501 Class A1 fire rating standards.
They also feature low VOC emissions, less than 0.5 milligrams per square meter per hour, creating a healthy indoor learning environment.
They can be easily installed with a T grid system and combined with lighting fixtures for a clean, modern ceiling appearance.
3. Healthcare and Laboratory Areas
Hospitals and laboratories need materials that combine hygiene, fire resistance, and acoustic control. ISOKING mineral wool panels use a non-porous laminated surface to resist dust and microbial growth.
They maintain stable dimensions in environments with up to 95 percent relative humidity and provide continuous sound absorption without deformation.
These panels are widely used in patient rooms, operating theaters, and clean laboratories.
4. Public and Transportation Spaces
Public spaces such as airports, metro stations, and exhibition halls require durable and safe acoustic materials. ISOKING mineral wool ceiling panels provide Class A fire safety and strong impact resistance up to 10 joules.
They can integrate easily with ventilation systems and lighting channels to achieve acoustic zoning and visual consistency.
They are suitable for auditoriums, terminals, and large conference centers.
Technical Advantages Summary
NRC 0.80 to 0.90
Fire Rating Class A EN13501 A1
Humidity Resistance up to 95 percent RH
Installation Options: T grid system
About IKING — Data-Driven Manufacturing for Better Insulation
For more than 19 years, IKING has been focusing on the manufacturing of insulation and acoustic materials, including glass wool, rock wool, and related systems.
99.7% on-time delivery rate
<0.3% defect rate
100% traceability for every batch
